SPECIFICATIONS

surveillance camera: For analog Home Surveillance DVR Systems

Weather: Resistant

Viewing Angle: 90°

Video Compression Format: H.265

Technology: Infrared

Style: Bullet Camera

Singal mode: TVI/AHD/CVI/CVBS 960H.

Sensor Size: 1/3"

Sensor: CMOS

Resolution:: 1080P

Origin: Mainland China

Model Number: 1AC-1062C-BS

Lens (mm): 3.6mm

Installation: Side

IR Distance: up to 80ft

Focal Length: 3.6mm

Connectivity: Closed System/CCTV Wired

Certification: CE, FCC

Brand Name: ZOSI

Noted Before Buy:

This camera did not come with DVR, power supply &video power cable!
1, this is a hard-wired camera, it needs to connect the CCTV cable and power supply( NOT included).
2, this camera could not work separately, it need to connect to the DVR to work.

Package Include:

1 x Outdoor/Indoor 1080P IR Color CMOS Camera
1 x Mounting Screw bag
1x Instruction Manual

ZOSI 2.0MP 1080p 1920TVL Outdoor Indoor Security Camera, Hybrid 4-in-1 TVI/CVI/AHD/CVBS CCTV Camera,80ft IR Night Vision Weatherproof For 960H,1080P,5MP,4K analog Home Surveillance DVR System

1080p Full HD Resolution

See everything in detail with true 1080p HD resolution. Get clearer and smoother images/videos than 720p cameras.

4-IN-1 Security Camera Specification

Image Sensor: 1/3〞CMOS CMOS with IR-Cut.
Active Pixels: 1920(H)×1080(V).
Resolution: 1080P.
Lens: 3.6mm
LEDs Amount: 24pcs, 5mm LEDs
Singal mode: TVI/AHD/CVI/CVBS 960H.
IR Distance: up to 80ft
Weather - Resistant

CVBS/CVI/AHD/TVI 4-In-1 Camera

This 1080p full HD camera has a built-in OSD menu that can change the 4 different video outputs： HD-TVI, AHD, CVI, and CVBS(960H)， and adjust the video settings.

Operation Mode：
Switch from AHD: Press Leftward for 5 Seconds

Switch from TVI: Press Rightward for 5 Seconds

Switch from CVBS: Press Upward for 5 Seconds

Switch from CVI: Press Downward for 5 Seconds

Noted: Default Video Mode is Analog 960H Mode

Weather Resistant Camera

The camera used high-quality materials, which can effectively prevent rust, water, etc. Can be installed outdoors or indoors.

Multiple Application Camera

It could be widely installed in homes, stores, offices, schools, and any place. Protect your family, parents, baby, property, and everything.

Troubleshooting

Q: Video Loss appears where the image from my camera should be displaying on my DVR.

A: 1. Check the extension cable (power and video) is securely connected to the camera.

2. Check the video output from the camera is securely connected to a video input channel on the DVR.

3. Check the power from the camera is securely connected to a power supply.

4. The camera mode does not match your DVR. There are 2 ways to set up. (1) Press OSD Joystick “DOWN” for 5 seconds, if still no picture comes, try to press “LEFT” “RIGHT” or” UP” for 5 seconds, till the signal matches your DVR. (2) Make sure the signal of your DVR, Use OSD Joystick to change the mode of the camera according to your DVRs video Mode.
